Pentair IntelliFlo VF

Select Manufacturer

Pentair

IntelliFlo VF 3.2 KW

Legend	Code	Name	Unit Price
	350202	Whisperflo Seal plate with Ceramic Seals and Gasket Legend: Code: 350202 Unit Price: $124.19	$124.19
	350122	50 ft. Communication Cable Legend: Code: 350122 Unit Price: $120.72	$120.72
2	070429	Bolt, hex HD, 2-56 x .875 S/S, 4 req. Legend: 2 Code: 070429 Unit Price: $3.49	$3.49
3	070430	Bolt, 3/8, 16 x 1-1/4 hex cap 18-8 S/S, 4 req. Legend: 3 Code: 070430 Unit Price: $3.99	$3.99
4	070431	Bolt, 3/8 -16 x 2 hex cap 18-8 S/S, 2 req. Legend: 4 Code: 070431 Unit Price: $5.00	$5.00
5	070927	Foot WF, pump motor support, almond Legend: 5 Code: 070927 Unit Price: $40.00	$40.00
6	070929	Foot insert WF pump, almond Legend: 6 Code: 070929 Unit Price: $21.00	$21.00
7	071131	Plug drain WFE, almond, 2 req. Legend: 7 Code: 071131 Unit Price: $6.74	$6.74
8	071403	Nut, 3/8, 16 brass nickel plated, 2 req. Legend: 8 Code: 071403 Unit Price: $1.00	$1.00
9	071406	Nut, 1/4, 20 hex S/S, 2 req. Legend: 9 Code: 071406 Unit Price: $2.99	$2.99
11	071652	Whisperflo Impeller Screw Legend: 11 Code: 071652 Unit Price: $4.14	$4.14
12	071657	Screw, 1/4, 20 x 1 in. hex cap 18-8 S/S, 2 req. Legend: 12 Code: 071657 Unit Price: $2.99	$2.99
13	071660	Diffuser Screw set, 4-40 x 1-1/8 WFE sckt cap 18-8 S/S, 2 req. Legend: 13 Code: 071660 Unit Price: $4.49	$4.49
14	072183	Washer, flat 1/4 x 5/8 20GA thick 18-8 S/S, 2 req. Legend: 14 Code: 072183 Unit Price: $1.00	$1.00
15	072184	Washer, 3/8 ID x 7/8 OD .05 thick 18-8 S/S, 6 req. Legend: 15 Code: 072184 Unit Price: $1.72	$1.72
16	072928	Whsperflo Diffuser 3 HP. Legend: 16 Code: 072928 Unit Price: $71.76	$71.76
17	073131	Whisperflo Impeller 3 HP. Legend: 17 Code: 073131 Unit Price: $75.90	$75.90
18	075713	Rubber washer WFE pump, 1 req. Legend: 18 Code: 075713 Unit Price: $1.00	$1.00
19	192115	O-ring 112, .487 x .103 buna -N 70, 2 req. Legend: 19 Code: 192115 Unit Price: $2.99	$2.99
20	350013	O-ring lid CH/WF 2-436, 1 req. Legend: 20 Code: 350013 Unit Price: $6.77	$6.77
21	350015	Housing WFE, almond Legend: 21 Code: 350015 Unit Price: $310.50	$310.50
23	357100	Black Gasket for Seal plate 1 Legend: 23 Code: 357100 Unit Price: $6.35	$6.35
24	357156	Lid, Chemical Resistant Legend: 24 Code: 357156 Unit Price: $48.31	$48.31
24	357151	Lid, see thru WF Legend: 24 Code: 357151 Unit Price: $38.64	$38.64
25	357199	Clamp, Cam & Ramp, plastic, almond (current) Legend: 25 Code: 357199 Unit Price: $34.04	$34.04
27	350601	Control cover assy. kit, almond (contains cover assy., hardware/ gasket kit, instr.) Legend: 27 Code: 350601 Unit Price: $247.02	$247.02
28	356880Z	INTELLIFLO VSF DRIVE ASSY BOTTOM Legend: 28 Code: 356880Z Unit Price: $0.00	$0.00
29	352401	Motor fan kit, almond (contains fan shroud, fan, hardware) Legend: 29 Code: 352401 Unit Price: $134.56	$134.56
30	350305S	Pentair Intelliflo Replacement Motor Legend: 30 Code: 350305S Unit Price: $725.00	$725.00
31	350612	Hardware/gasket assy. kit (contains 3 screws, 3 spacer caps and drive gasket) Legend: 31 Code: 350612 Unit Price: $77.15	$77.15
32	070112	Power end IntelliFlo VF, almond (contains items: 2, 4, 10, 11, 13, 15, 16, 17, 19, 22, 23, 28, 30) Legend: 32 Code: 070112 Unit Price: $2,117.92	$2,117.92
