Features: Raypak's Low Emissions units use combustion control to minimize levels of nitrogen oxides (NOx). The units meet emissions standards in all Low NOx areas, from Los Angeles (SCAQMD Rule 1146.2 certified) through the San Joaquin Valley (SJAPCD Rule 4308), and any other areas applying the stringent SCAQMD standard - the "Gold Standard" of emissions regulations - to residential pool heaters. Available for natural gas only Digital Controls provide solid-state reliability and accuracy and clear diagnostics. Setting it for the temperature you want is a snap...push a few buttons and walk away. PolyTuf Textured Powder Coating The Raypak gas heater has a polyester-coated, non-corrosive cabinet that is more durable than solventborne- and waterborne-coated metal cabinets. Every piece of sheet metal goes through a 7-stage wash system, making certain the powder paint has a perfect bond. Underneath the tough, yet beautiful finish you will find galvanized metal that offers superior rust prevention and years of durable service Wind-Resistant Design No need for fans to combat drafting problems. This heater is designed to draft naturally in outdoor installations with its exclusive low-profile design. It is so thoughtfully and carefully designed it actually protects itself from the things that tend to stifle ordinary pool and spa heaters. It delivers uninterrupted heating performance regardless of falling leaves, wind, airborne debris, rain, downdrafts, updrafts, sleet, snow, etc. Polymer Headers Polymer headers prevent rust stains from harming your pool’s surface, giving you years of trouble-free swimming pleasure. All-Copper-Fin-Tube Heat Exchanger The fin tubes of the heat exchanger are each made from a single piece of extruded copper. This integral-fin design allows maximum heat transfer to be attained and maintained. These headers are specifically designed for the residential market...for commercial installations, use the ASME models. Stainless Steel Tube Sheet Stainless steel tube sheets are used on all Raypak gas heaters. This allows for a completely nonferrous waterway, leaving your pool truly rust-free. CPVC 2" Water Connections Standard with every Raypak is a set of 2" slip-fit CPVC water connections to make your installation secure and effortless. Condensation Protection The Unitherm Governor inside the header helps reduce condensation from low inlet water temperatures. It automatically regulates the water flow to help keep the water temperature in the heat exchanger above 105°F. Both water temperature and water flow rate are controlled to eliminate condensation, sooting, and scale build-up that can shorten heater life. High Flow Rates The Raypak gas heater comes with an automatic bypass built into the header. You'll find that the heater is capable of handling water flow at a rate up to 125 GPM. Burner Tray Every burner tray is built to last, from the stainless steel burners to the aluminized metal used in the heat sensitive areas. Innovative design allows for the easy removal of the tray and burners for servicing. Fire Tile A ceramic fiber combustion box keeps your heater running efficiently while keeping the outside jacket cool. By using this space-age material the heater won't retain residual heat after it is turned off, allowing it to be installed without the use of costly metal heat sinks. Fuel-Efficient Energy-smart Raypak heaters consistently achieve the highest efficiency ratings. They exceed all federal and state standards. BASIC DATA
1 year manufacturer warranty. Please refer to owner manual for details.
OWNER'S MANUAL ILLUSTRATED DIAGRAM AND PART LIST BROCHURE
