Pro Series Plus Side-Mount Sand Filter IN STORE SALE ONLY

Pro Series Plus Side-Mount Sand Filter IN STORE SALE ONLY

0 reviews / Write a review

  • $1,606.26

  • Product Code: S360SX

Qty
  • Description
  • Warranty
  • Reviews (0)

Incorporating the many advanced features of Hayward`s Pro™ Series side-mount sand filter, the Pro Series Plus satisfies the requirements of the most demanding installations, including pools installed with in-floor cleaning systems, spas, fountains or solar heating systems. Its spherical tank design evenly distributes the high pressure and stress associated with these applications, resulting in greater strength and longer life. Note: Valve is NOT included.

Applications

  • In-ground pools installed with in-floor cleaning systems, solar heating systems, water features
  • In-ground spas or in-ground pool/spa combinations

Features

  • Durable, flanged inspection cover provides convenient access to top of filter
  • Top diffuser ensures even distribution of water over the top of the sand media bed. All internal piping is 2" to give smooth, free-flowing performance
  • Automatic air relief purges any trapped air during operation of the filter system
  • Unitized, corrosion-proof, spherical filter tank molded of rugged, colorfast polymeric material for maximum strength and longer life
  • Optional valve and coupling selections for plumbing ease and versatility. Choose from 7-position Vari-Flo™ valve, 2-position slide valve or 1 1/2" SKT x 2" SLIP connectors for multiple (tandem) filter installations
  • Precision engineered umbrella-fold self cleaning laterals for balanced flow and backwashing, plus easy serviceability
  • NEW Large pressure sand/water drain for rapid winterizing or servicing

Performance Data - Filter



Turnover (In Gallons)
Model Number
Effective Filtration Area
Design Flow Rate*
8 Hours
10 Hours
S311SX
4.95 ft2
99 GPM
47520
59400
S360SX
6.50 ft2
130 GPM
62400
78000

 Performance Data - Valve Positions



Model No
Filter
Backwash
Waste
Recirculate
Rinse
Closed
DE2400PAK2CS
+
----
----
----
----
----
SP0715X62
+
+
+
+
+
+
SP0410X602S
+
+
----
----
----
----
SP0710X62
+
+
+
+
+
+

 Technical Specifications



Pro Series Plus Side-Mount Sand Filter Buying Guide
Model Number
Valve
Sand Required
Dimensions
Width** Height
Ctn. Qty.
Ctn. Weight
S311SX
Not Included*
350 lbs
31"
  38 5/8"
1
74 lbs.
S360SX
Not Included*
700 lbs
36"
46"
1
95 lbs.
*Order valve separately-See "Valve and Coupling Selections" Buying Guide.
**Above dimensions are for filter only. Add 12" for 1 1/2" and 14" for 2" multiport valves. Add 7" for 2" slide valve.
Valve and Coupling Sections
Model Number
Description
Pipe Size
Valve Positions
Ctn. Qty.
Ctn. Weight
SP0710X62
Vari-Flo
1 1/2" FIP
6
1
6 lbs.
SP0715X62
Vari-Flo
2" FIP
6
1
9 lbs.
SP0410X602S
Slide Valve
2" SKT
2
1
4 lbs.
DE2400PAK2CS
Coupling (2)
1 1/2" SKT x 2" SLIP
--
10
12 lbs.






1 Year Limited Warranty. Please refer to owner's manual.
